Customizable 5kw/piece LiFePO4 Battery 48v 100ah Solar Energy System Battery Storage
Product Details:
| Place of Origin: | Anhui, China |
| Brand Name: | SUNWAY |
| Certification: | CE/RoHS/UN38.3/MSDS |
| Model Number: | Stackable |
Payment & Shipping Terms:
| Price: | $365.00 - $1,460.00/pieces |
|---|---|
| Packaging Details: | UN caton box with pallet<br>Customizable 5kw/piece lithium ion battery 48v 100ah solar energy system battery storage lithium battery |
| Supply Ability: | 800 Piece/Pieces per Month |
|
Detail Information |
|||
| Battery Type: | LiFePO4 | Application: | Solar Storage Appliances |
|---|---|---|---|
| Cycle Life: | 6000 Times | Capacity: | 5-20KWH |
| Warranty: | 5 Years | Nominal Voltage: | 51.2Volts-384Volts |
| Battery Cell: | A Grade 3.2V | OEM/ODM: | Accepatable |
| Type: | Li-Ion/lithium/lifepo4 | Inverter Matched: | Deye/Growatts/Sofar/etc |
| Power Source: | Solar Panel | Special Features: | External Battery |
| Port: | Ningbo Shanghai | ||
Product Description
Key Features
Stackable type: Easy connection, support max 8 set parallel connection. Longer Cycle Life : Offers up to 5000 times longer cycle life and five times longer float/calendar life than lead acid battery , helping to minimize replacement cost and reduce total cost of ownership Lighter Weight : About 40% of the weight of a comparable lead acid battery . A " drop in" replacement for lead acid batteries Higher Power : Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity Wider Temperature Range : -20ºC~60ºC Superior Safety: Lithium Iron Phosphate chemistry eleminates the risk of explosion or combustion due to high impact overcharging or short circuit situation
Electrical Characteristics | Nominal Voltage | 51.2-384 |
Nominal Capacity | 100Ah/200Ah | |
Energy | 5KWH,10KWH,15KWH,20KWH | |
Internal Resistance(AC) | ≤20mΩ | |
Cycle Life | >5000 cycles @ 1C 80% DOD | |
Months Self Discharge | <3% | |
Efficiency of Charge | 100% @0.5C | |
Efficiency of Discharge | 96~99% @1C | |
Standard Charge | Charge Voltage | 58.4±0.2V |
Charge Current | 1C max, default 0.5C | |
Max. Charge Current | 1C max, default 0.5C | |
Charge Cut-off Voltage | 62.4±0.2V | |
Standard Discharge | Continuous Current | 1C max, default 0.5C |
Discharge Cut-off Voltage | 43.2V | |
Environmental | Charge Temperature | 0ºC to 55ºC (32F to 131F) @60±25% Relative Humidity |
Discharge Temperature | -20ºC to 60ºC (-4F to 140F) @60±25% Relative Humidity | |
Humidity | ||
Storage Temperature | -20ºC to 60ºC (-4F to 140F) @60±25% Relative Humidity | |
IP Class | IP30 |
